0i/0i Mate - Model C Parameter manual Page 371

Parameter manual
B-64120EN/01 4.DESCRIPTION OF PARAMETERS
- 359 -
1 : Used.
For axes under simple synchronization control, when the external
machine coordinate system shift is performed for the master axis, it
can also performed for the slave axis simultaneously.
NOTE
The simple synchronous signal must be
manipulated.
Carefully turn the simple synchronous signal on
and off because the machine may move at that
time.
SMA When bit 4x (APZx) of parameter No. 1815 is turned off for one axis
under simple synchronous control, APZx for the other axis under
simple synchronous control is:
0 : Not turned off.
1 : Turned off.
When an axis for which the simple synchronous axis parameter is set
is under simple synchronous control, the simple synchronous signal is
turned on for the axis.
#7 #6 #5 #4 #3 #2 #1 #0
8303
SOFx ATSx ATEx
NOTE
After this parameter has been set, the power must
be turned off then on again for the setting to
become effective.
[Data type] Bit axis
ATEx In simple synchronous control, automatic setting for grid positioning
is:
0 : Disabled.
1 : Enabled.
ATSx In simple synchronous control, automatic setting for grid positioning
is:
0 : Not started.
1 : Started.
NOTE
When starting automatic setting for grid positioning,
set ATSx to 1. Upon the completion of setting,
ATSx is automatically set to 0.
SOFx In simple synchronous control, the synchronization function is:
0 : Not used.
1 : Used.
