0i/0i Mate - Model C Parameter manual Page 81

Parameter manual

Page of 414

/ 414

B-64120EN/01 4.DESCRIPTION OF PARAMETERS

- 69 -

1428 Reference position return feedrate

[Data type] 2-word axis

[Unit of data, valid data range]

Valid data range

Increment system Unit of data

IS-A, IS-B IS-C

Millimeter machine 1 mm/min 30 to 240000 6 to 100000

Inch machine 0.1 inch/min 30 to 96000 6 to 48000

Rotation axis 1 deg/min 30 to 240000 6 to 100000

This parameter sets a rapid traverse rate for reference position return

operation using deceleration dogs, or for reference position return

operation before a reference position is set.

This parameter is also used to set a feedrate for the rapid traverse

command (G00) in automatic operation before a reference position is

set.

NOTE

1 This parameter is invalid for an axis using the scale

with absolute addressing reference marks.

2 When 0 is set in this parameter, this parameter

disables the reference position return feedrate

setting function.

Before a reference position is set After a reference position is set

No. 1428 No. 1428

=0 ≠0 =0 ≠0

Reference position return by G28

Raped traverse command (G00) in

automatic operation

No.1420 No.1420

Without dogs

(*1)

No.1420 or No.1424

(*3)

Manual reference

position return

With dogs

(*1)

No.1424

No.1428

No.1424 No.1428

Manual raped traverse No.1423 or No.1424

(*2)

No.1424

*1 With/without dogs: Reference position return operation not

using/using deceleration dogs

*2 For manual rapid traverse before a reference position is set, a jog

feedrate (parameter No.1423) or manual raped traverse rate

(parameter No.1424) is used according to the setting of bit 0

(RPD) of parameter No.1401.

*3 The rapid traverse rate set in parameter No.1424 or No.1420 is

used according to the setting of bit 1 (DLF) of parameter

No.1404 when reference position return is performed without

dogs, or when reference position return operation is performed

with bit 7 (SJZ) of parameter No.0002 set to 1 after a reference

position is set (when reference position return operation is

performed using rapid traverse without deceleration dogs).
