OPEN CNC (Machining Status Monitoring Package) Operators manual Page 142

Operators manual
5. SETTING AND REGISTERING DATA FOR EACH CNC MACHINE B-63364EN/03
- 126 -
From the item type list, select the item type to be registered.
3. Register a log output item. No values need be set in those cells shown by
hatching.
For details of registering monitor items and log output items, see Section
5.2.2, "Example of Registering and Changing Monitor Items and Log
Output Items."
4. To save the data set using the assistance lists, click the <Save Combo Box
Data> button. The contents of the assistance lists are reflected in the cells.
To cancel the data set using the assistance lists, click the <Cancel Combo
Box Data> button.
The assistance lists, the <Save Combo Box Data> button, and the <Cancel
Combo Box Data> button disappear.
NOTE
If the CNC machine does not support the "Machining Time, Parts
Count" options, the item "Parts Total" and the subsequent items do
not appear on the item type list.
If, however, the existence or absence of the options cannot be
determined for reasons such as the disconnection of the power from
the CNC machine, all the items are shown.
