1. DISPLAY AND OPERATION
77
410 Load meter of 1st spindle [%]
DGN
411 Speed meter of 1st spindle [min
–1
]
DGN
412 Load meter of 2nd spindle [%]
DGN
413 Speed meter of 2nd spindle [min
–1
]
DGN
414 Position error in 1st spindle synchronous control mode
DGN
415 Position error in 2nd spindle synchronous control mode
DGN
416 Absolute value of synchronization error between 1st and 2nd spindles
DGN
417 Feedback information of 1st spindle position coder
DGN
418 Position error of 1st spindle position loop mode
DGN
419 Feedback information of 2nd spindle position coder
DGN
420 Feedback information of 2nd spindle position coder
DGN
425 First–spindle synchronization error
DGN
426 Second–spindle synchronization error
DGN
No. 425 to 428: Indicates the absolute value of a synchronization error in synchronization
mode where each spindle is treated as a slave axis.
NOTE
1 The temperature data must fall within the following ranges.
D 50_C to 160_C "5_C
D 160_C to 180_ C "10_C
2 The indicated temperature and the temperature at which
overhear occurs have the following errors.
D 160_C or less Up to 5_ C
D 160_C to 180_ C Up to 10_C
3 For spindles older than the αi spindle, this function is invalid.
4 When the system configuration of the spindle (even another
spindle) includes an additional spindle older than the αi
spindle, this function is invalid.
445 First–spindle position data
DGN
446 Second–spindle position data
DGN
[Data type] Word
[Unit of data] Pulse
[Valid data range] 0 to 4095
This parameter is valid when bit 1 of parameter No. 3117 = 1.
To display the position data of a spindle, execute spindle orientation.
