Model Item Drawing No. Remarks
0i–C
Basic unit without slot A02B–0309–B500
0i–C
Basic unit with 2 slots A02B–0309–B502
0i Mate–C Basic unit without slot A02B–0311–B500
Model Item Drawing No. Remarks
Common
Case without slot A02B–0236–D100#0C
Common
Case with 2 slots A02B–0236–D100#2C
Model Item Drawing No. Remarks
Common
7.2
″
LCD/MDI unit
A02B–0309–D502#T Horizontal type T series
Common
7.2 LCD/MDI unit
A02B–0309–D502#M Horizontal type M series
A02B–0309–D503#T Vertical type T series
A02B–0309–D503#M Vertical type M series
0i–C
8.4
″
LCD/MDI unit
A02B–0309–D504#T Horizontal type T series
0i–C
8.4 LCD/MDI unit
A02B–0309–D504#M Horizontal type M series
A02B–0309–D505#T Vertical type T series
A02B–0309–D505#M Vertical type M series
2.5
