B–64115EN/01

3. INPUT AND OUTPUT OF DATA

231

1. Set to the emergency stop state.

2. Confirm that the patameters required to input data is correct.

In addition, l indicates the standard setting for input/output devices

made by FANUC. Change these settings according to the unit you

actually use.

1) Press

OFFSET

SETTING

key several times, and press [SETING] to display

SETTING screen.

2) Confirm that PARAMETER WRITE=1.

3) Press

SYSTEM

key to select the parameter screen.

0020 Selectionof I/O channel

l 0 : Channel 1 (JD36A of mother board)

1 : Channel 1 (JD36A of mother board)

2 : Channel 2 (JD36B of mother board)

NFD0101

#6 #5 #4 #3

ASI

#2 #1 #0

SB2

#7 (NFD) 0 : Feed is output when punching out.

1 : Feed is not output when punching out.

#3 (ASI) 0 : EIA or ISO code is used.

1 : ASCII code is used.

#0 (SB2) 0 : No. of stop bits is 1.

l 1 : No. of stop bits is 2.

0102 Specification number of I/O device

Set value Input/output device

0 RS–232–C (Used control codes DC1 to DC4)

1 FANUC CASSETTE ADAPTOR 1 (FANUC CASSETTE B1/ B2)

2 FANUC CASSETTE ADAPTOR 3 (FANUC CASSETTE F1)

3 FANUC PROGRAM FILE Mate, FANUC FA Card Adaptor

FANUC FLOPPY CASSETTE ADAPTOR, FANUC Handy File

FANUC SYSTEM P-MODEL H

4 RS–232–C (Not used control codes DC1 to DC4)

5 Portable tape reader

6 FANUC PPR

FANUC SYSTEM P-MODEL G, FANUC SYSTEM P-MODEL H

3.2.8

Inputting CNC

Parameters
