0i/0i Mate - Model C Maintenance manual Page 284

Maintenance manual
3. INPUT AND OUTPUT OF DATA
B–64115EN/01
260
6 With page keys
PAGE
and
PAGE
, scroll through the file directory or
program directory.
7 When this screen is displayed, the program data item is selected. The
soft keys for other screens are displayed by pressing the rightmost soft
key
(continuous menu key).
(OPRT)PITCH WORK
When a data item other than program is selected, the screen displays only
a file directory.
A data item is indicated, in parentheses, on the title line.
READ/PUNCH (PARAMETER)
No. FILE NAME SIZE DATE
O0001 N00001
0001 O0222 332010 96/04/06
0002 O1003 334450 96/05/04
0003 MACROVAR.DAT 653400 96/05/12
0004 O0003 334610 96/05/04
0005 O0001 334254 96/06/04
0006 O0002 333750 96/06/04
0007 CNCPARAM.DAT 334453 96/06/04
~ ~
8 Display the following soft keys with soft key [(OPRT)].
F SRH DELETEN READF READ PUNCH
The operation of each function is the same as on the directory (memory
card) screen. Soft key
[O SET], used for program number setting, and the
“PROGRAM NUMBER =” indication are not displayed for data items
other than program.
[F SRH] : Finds a specified file number.
[F READ] : Reads a specified file number.
[PUNCH] : Writes a file.
[N READ] : Reads a file under a specified file name.
[DELETE] : Deletes a specified file number.
