4. INTERFACE BETWEEN CNC AND PMC
B–64115EN/01
276
D Function instruction number [F-SRCH] or
Function instruction name [F-SRCH]: Searches for the specified
function instruction.
D [ADRESS]:
Displays the address and bit number of the specified signal.
D [SYMBOL]:
Displays the symbol of the specified signal. (The address of the
specified signal is displayed if a symbol was not specified when
the program was created.)
(4)Turning off the monitor display when the trigger signal changes
(TRIGER)
When the preset trigger signal changes, the system turns off the
monitor display. By using this function, the states of all signals can
be accurately read when the trigger signal changes.
1 Press the [TRIGER] soft key.
SEARCH ADRESS TRIGER WINDOW
NEXT
TRGON TRGOFF START
DUMP DPARA TRGSRC INIT
RET
2 Press the [INIT] soft key to initialize the trigger parameters.
3 Specify the trigger conditions.
D To turn off the monitor display at the signal’s rising edge (as the
signal changes from 0 to 1), enter the desired data and press the
required keys in the order shown below.
Signal name/address EOB Trigger checkpoint EOB
Count [TRGON]
: Trigger checkpoint:
0: Before the first level of the ladder program is executed
1: After the first level of the ladder program is executed
2: After the second level of the ladder program is executed
3: After the third level of the ladder program is executed
Example) To set the system so that it turns off the monitor display
when the external reset signal (ERS) is input three times, enter the
required data and press the required keys in the order shown below:
ERS EOB
[TRGON]
2 EOB 3
