4. INTERFACE BETWEEN CNC AND PMC

B–64115EN/01

280

: The operations that can be performed in on-line editing are

restricted to those that do not change the memory size of the

program. To perform other operations, such as addition,

insertion, and deletion, use the ordinary editing function.

3 To terminate on-line editing, press the

key.

: Changes made in on-line editing are temporary. To save a

changed program, set K18.3 to 1 or transfer the program to the

DRAM by using the COPY function from the I/O screen. To

enable the use of the program when the system is next turned on,

write it to the FROM from the I/O screen.

K018

#6 #5 #4 #3 #2 #1 #0

PMCPRM

#3 0 : The ladder program is not transferred to the RAM after on-line

editing.

³ To transfer the program, press the following keys in the order

shown, using the COPY function from the I/O screen:

[COPY], [EXELAD], [EXEC]

1: A ladder program is automatically transferred to the RAM after

on-line editing.

(1)Display method

1 Press the

SYSTEM

key.

2 Press the [PMC] soft key.

3 Display of PMC diagnosis screen by pressing [PMC/DGN] soft

key.

Display of the title data which is wrote at the ladder programming time.

PMC TITLE DATA #1

PMC PROGRAM NO. :

EDITION NO. :

PMC CONTROL PROGRAM

SERIES : 408B EDITION : 01

(SERIES : EDITION : )

PMC TYPE CONTROL : RB5 PROGRAM : RB5

MEMORY USED : KB

LADDER : KB

SYMBOL : KB

MESSAGE : KB

SCAN TIME : MS

SCAN MAX : MS MIN : MS

MONIT RUN

TITLE

[][][][][]STATUS ANALYS TRACE

4.3.3

Display of PMC

Diagnosis Screen

4.3.3.1

Title screen (TITLE)
