0i/0i Mate - Model C Maintenance manual Page 50

Maintenance manual
1. DISPLAY AND OPERATION
B–64115EN/01
26
Types of PCBs mounted on the slots are displayed.
If a hardware trouble or an incorrect mounting is found, this screen is
displayed.
SLOT CONFIGURATION DISPLAY
0: 00184000 0:
1: E1AA5E08 1:
2: 008E6D01 2:
3: 3:
4: 4:
5: 5:
… …
Physical slot number (2ndary side)
Module ID of the PCB mounted (*1)
Physical slot number (primary side)
*1) Module ID of PCB
Internal slot number
Module function (software ID)
Type of PCB (module ID)
ff j j ∆ ∆
ID Name
18 Series 0i–C main CPU board
19 Series 0i Mate–C main CPU board
8E Data server board, Fast Ethernet board
CD Serial communication board/DNC2
AA HSSB interface board
40 : Main CPU
5E : HSSB interface (with PC)
6D : Fast Ethernet, Data server
1.2
SCREEN DISPLAYED
IMMEDIATELY AFTER
POWER IS TURNED
ON
1.2.1
Slot Status Display
D Slot state screen
D Module ID
D Software ID
