0i/0i Mate - Model C Maintenance manual Page 617

Maintenance manual
APPENDIX
B–64115EN/01
C. BOOT SYSTEM
593
This screen is used to delete a user file from flash ROM.
SYSTEM DATA CHECK 1/1
[BOARD:MAIN]
FILE DIRECTORY (FLASH ROM : 16MB)
1 NC BASIC ( 10)
2 NC2 BSIC ( 8)
3 DGB0SRVO ( 2)
4 PS0B406G ( 8)
5 PS1B406G ( 4)
6 PS2B406G ( 4)
7 ETH2 EMB ( 8)
END
*** MESSAGE ***
SELECT FILE AND HIT SELECT KEY.
[ SELECT ][ YES ][ NO ][ UP ][ DOWN ]
(1)
(2)
(3)
(4)
(5)
(1): Screen title
(2): Names of accessing board
(3): Names of files in flash ROM The number of management units
constituting each file appears in parentheses to the right of the file
name.
(4): Returning to the previous menu
If flash ROM contains many files, END is sometimes not displayed.
In this case, press the continuous menu key (
) of the soft key
display several times. Then, END appears at the end of files.
(5): Message
1 Position the cursor to the name of the file to be deleted. Press the
[SELECT] soft key.
2 The system displays the following confirmation message :
*** MESSAGE ***
DELETE OK ? HIT YES OR NO.
3 To start the deletion, press the [YES] key. To cancel, press [NO].
*** MESSAGE ***
DELETING ROM FILE IN FLASH MEMORY.
C.2.3
System Data Delete
Screen
D Description
D Screen configuration
D Operating procedure
