FANUC LASER-MODEL C1000iA Operators manual Page 56

Operators manual
5.TROUBLESHOOTING B-70254EN/01
- 52 -
No. Cause of trouble Solution
3 Invalid sensor setting
4 Sensor abnormal
It is necessary to replace or adjust the part.
Call the FANUC service center.
ALM No.4107
External reflecting mirror not installed
This alarm is issued, if the beam reflecting unit is not attached
with a mirror or mirror holder. (The C1000iA has no beam
folding unit.)
No. Cause of trouble Solution
1 Mirror not mounted Mount a mirror.
2 Sensor abnormal
3 Cable abnormal
It is necessary to replace or adjust the part.
Call the FANUC service center.
ALM No.4132
Parameter changed (warning)
Press the RESET key to release this alarm.
