C.2 PARAMETERS FOR DISCHARGE TUBE SELECTION
#7 #6 #5 #4 #3 #2 #1 #0
15025 PS8 PS7 PS6 PS5 PS4 PS3 PS2 PS1
15026 PS16 PS15 PS14 PS13 PS12 PS11 PS10 PS9
Data type: Bit
PS1 to PS16 Discharge tube selection when half of the discharge tubes are used
Set the bit for each discharge tube to be used to 1, and set the other
bits to 0.
NOTE
Parameter No. 15026 is provided for future addition of
discharge tubes. In the current specifications, this
parameter is not used. Set all bits to 0.
#7 #6 #5 #4 #3 #2 #1 #0
15027 PS8 PS7 PS6 PS5 PS4 PS3 PS2 PS1
15028 PS16 PS15 PS14 PS13 PS12 PS11 PS10 PS9
Data type: Bit
PS1 to PS16 Discharge tube selection when all discharge tubes are used
Set the bit for each discharge tube to be used to 1, and set the other
bits to 0.
NOTE
Parameter No. 15028 is provided for future addition of
discharge tubes. In the current specifications, this
parameter is not used. Set all bits to 0.
