  2. FS 16i/18i/21i-MA/TA, Automatic Operation and Temporary Storage of External Program

FS 16i/18i/21i-MA/TA, Automatic Operation and Temporary Storage of External Program Supplement to Manual Page 1

Supplement to Manual
FANUC Series 16i /18i
/21i
– MA/TA
Automatic operation and temporary storage
of external program
Index
1. Genaral...........................................................................................................................2
2. Specifications .................................................................................................................3
2.1 Size of temporary storage memory ....................................................................3
2.2 Range of part program on temporary storage memory ....................................3
2.3 Display of program directory screen ..................................................................4
2.4 Number of registered part program on the temporary storage memory .........4
2.5 Program edit of part program on the temporary storage memory 5
2.6 Registration and deletion of part program
on the temporary storage memory by M code ..............................5
2.7 Execution of the program on the temporary storage memory .........................6
3. Example .........................................................................................................................7
4. Notes ..............................................................................................................................8
5. Parameters...................................................................................................................10
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
1
/
1
Date
Design
Descri
p
tion
Date
FANUC Series16i/18i/21i–MA/TA
Automatic operation and temporary
storage of external program
ith M l M
A
-78620
09.Oct.’01 T.Endo H.Kochiya
Previous page
Next page
