1. AC Spindle motor model αiIL 26/15000
Output characteristics
(Applied spindle amplifier: αiSP 37 )
Cooling machine capacity:4.1kW(3500kcal/h)
(1) Low speed winding (Star connection)
0
5
10
15
20
25
30
0 500 1000 1500 2000
(2) High speed winding (Star connection)
0
10
20
30
40
0 5000 10000 15000
Note 1) Maximum output power during acceleration to select αiPS is 45kW.
(This is not a guaranteed value but a guideline.)
AA-221284/02E
Output (kW)
Motor speed (min
-1
)
Continuous operating zone
S3 15% operating zone
520
15kW
22kW
Output (kW)
Motor speed (min
-1
)
30kW
26kW
Continuous operating zone
30min, S3 60% operating zone
18.5kW
15kW
S3 25% operating zone
2600
37kW
S3 40% operating zone
6000
403Nm
