B-65262EN/03 FANUC AC SERVO MOTOR α(HV)iS SERIES 3.SPECIFICATIONS AND CHARACTERISTICS

- 203 -

odel Specificatio

A06B-0213-B

□

Data sheet

Parameter Symbol Unit

Stall Torque

(*)

Ts 2 Nm

20 kgfcm

Stall Current

(*)

Is 1.6 A (rms)

Rated Output

(*)

Pr 0.75 kW

1.0 HP

Rating Speed

Nr 4000

min

-1

Maximum Speed

Nmax 5000

min

-1

Maximum Torque

(*)

Tmax 7.8 Nm

80 kgfcm

Rotor Inertia

Jm 0.000291

kgm

0.00297

kgfcms

Rotor Inertia (with Brake)

Jm 0.000311

kgm

0.00317

kgfcms

Torque constant

(*)

Kt 1.22 Nm/A (rms)

12.4 kgfcm/A (rms)

Back EMF constant (

１

１１

１

phase)

(*)

Ke 42

V (rms)/1000 min

-1

Kv 0.40 V (rms)sec/rad

Armature Resistance (1 phase)

(*)

Ra 5.4

Mechanical time constant tm 0.003 s

Thermal time constant tt 15 min

Static friction Tf 0.1 Nm

1kgfcm

Weight w2.8 kg

Weight (with Brake) w3.8 kg

Maximum Current of Servo Amp. Imax 10 A (peak)

Value

(*) The values are the standard values at 20

℃

and the tolerance is ±10%.

The speed-torque characteristics very depending on the type of software, parameter setting,

and input voltage of the digital servo software. (The above figures show average values.)

These values may be changed without notice.

@2/5000HV*s

Over Load Duty

100

1 10 100 1000 10000

"On" time (sec)

Duty (time%)

Speed-Torque Characteristics

0 2000 4000

Speed (min

-1

)

Torque (Nm)

Intermitting

Operation

110%

120%

130%

140%

150%

170%

210%

MAX

Continuous

Operation
