Date Design Description

FANUC AC SERVO MOTOR αis/αi series DESCRIPTIONS

FANUC AC SERVO MOTOR βis series DESCRIPTIONS

High speed AC Servo motor for live tool

B-65262EN/03-6, B-65302EN/01-1

04.09.02 T.Tamaki

Draw.

Add High speed AC Servo motor for live tool

3. CHARACTERISTICS CURVE AND DATA SHEET

β0.5/6000iS page 5

β1/6000iS page 6

α2/6000iS page 7

α8/6000iS page 8

α2/6000HViS page 9

α8/6000HViS page 10

4. OUTLINE DRAWINGS

Model Fig. No.

Models β0.5iS and β1iS Fig.4(a)

Models β0.5iS and β1iS (with brake) Fig.4(b)

Model β0.5iS (shaft option) Fig.4(c)

Model β1iS (shaft option) Fig.4(d)

Models β0.5iS and β1iS(engaged with the connector)

(elbow type)

Fig.4(e)

Models β0.5iS and β1iS (engaged with the connector)

(straight type)

Fig.4(f)

Models α2iS Fig.4(g)

Models α2iS (with brake) Fig.4(h)

Model α2iS (shaft option) Fig.4(i)

Models α8iS Fig.4(j)

Models α8iS (with brake) Fig.4(k)

Model α8iS (shaft option) Fig.4(l)

Note) Each specification is the same as standard motor(αiS) and

convetional motor(βiS) specification.

7.DATA FOR SELECTING PSM

Motor Model Rating output Maximum output at

accelerating

β0.5/6000iS 0.35kW 1.3kW

β1/6000iS 0.5kW 2.3kW

α2/6000iS 1.0kW 2.4kW

α8/6000iS 2.2kW 11kW

α2/6000HViS 1.0kW 2.4kW

α8/6000HViS 2.2kW 11kW

Note)

These data is only for selecting the PSM and it doesn’t guarantee the power of motors.
