B-65262EN/03 SPECIFICATIONS FOR THE αiS/αi SERIES 3.SELECTING A MOTOR

- 45 -

3.2 SELECTING A MOTOR

Sample model for calculations for selecting a servo motor

The following subsections explain how to calculate conditions for

selecting a servo motor best suited for a table with a horizontal axis

with the following specifications.

Sample mechanical specifications of the table and workpiece

W : Weight of movable parts (table and workpiece)

=11760[N]=1200[kgf]

w : Mass of movable parts (table and workpiece) =1200[kg]

µ : Friction coefficient of the sliding surface =0.05

η : Efficiency of the driving system (including a ball screw) =0.9

: Gib fastening force (kgf) =490[N]=50[kgf]

: Thrust counter force caused by the cutting force (kgf)

=4900[N]=500[kgf]

: Force by which the table is pressed against the sliding surface,

caused by the moment of cutting force =294[N]=30[kgf]

: Gear reduction ratio = 1/1

: Friction torque applied to the motor shaft =0.8[N⋅m]=8[kgf⋅cm]

Sample specifications of the feed screw (ball screw)

: Shaft diameter =40×10

-3

[m]=40[mm]

: Shaft length =1[m]=1000[mm]

P : Pitch =20×10

-3

[m/rev]=20[mm/rev]

Sample specifications of the operation of the motor shaft

: Acceleration torque [N⋅m][kgf⋅cm]

V : Workpiece rapid traverse rate =60[m/min]

: Motor speed in rapid traverse [min

-1

]

: Acceleration time (s) =0.08[s]

: Motor inertia [kg⋅m

][kgf⋅cm⋅sec

]

: Load inertia [kg⋅m

][kgf⋅cm⋅sec

]

: Position loop gain =30[s

-1

]
