Connecting Manual for Fanuc Panel i for Automotive Additional Manual Page 7

Additional Manual
FANUC PANEL i for automotive
connecting manual
EDIT
DRAW. NO. CUST
TITLE
DESCRIPTION
DESIG.
DATE
A
-83132E
7
/
SHEET
2.3. Power Specification
1) Power Supply Requirement
A) Specification
When the PANEL i for AUTOMOTIVE power supply is required.
Input Voltage DC +24V ± 10%
Current capacity 10A or more
Note: If Handy File or other unit made by FANUC is connected to RS232C port, this value will
increase by +1A.
B) Timing
In case that CNC and PANEL i for AUTOMOTIVE are connected with HSSB, the rotary switch on the
CNC side HSSB interface board decides if CNC and PANEL i for AUTOMOTIVE start independently or
synchronously.
2) Power Supply
Following powers are usable for peripherals using power supply as mentioned above.
Voltage Equipment Max. Current
Mouse
PCI extension board
USB device Max.500mA/port
+5V
PCMCIA card
1400mA in total
Max.500mA
+3.3V PCI extension board
PCMCIA card
1000mA in total
+12V
PCI extension board
PCMCIA card
500mA in total
-12V PCI extension board 100mA in total
-- POWER ON TIMING for the unit WITH I/O LINK OPTION --
This unit is the slave device of I/O Link. Turn ON or OFF the power for this unit
j
ust when the power for the master device (ex. CNC unit or the cell controller)
is turned ON or OFF. If the power is not turned ON and OFF according go the
above procedure, an error would occur in the master device, or this unit is not
normally connected via I/O Link.
(Refer to Connection manual for each CNC in detail.)
In case of I/O Link option is not exist, Input power can be turned on/off without relation
to CNC power on/off.
