5. TOOL FUNCTION (T FUNCTION)
B–63683EN/01
106
#7
UTL16280
#6
UTS
#5
UCT
#4
UPC
#3
UTC
#2
UOY
#1
UOX
#0
UT8
[Data type] Bit
This parameter is valid when the function used to set tool data is specified.
In the following description, n represents the number of tools to be stored.
UT8 As a tool number:
0 : Up to eight digits can be input. (n 4–byte numbers)
1 : Up to four digits can be input. (n 2–byte numbers)
UOX A tool position compensation value along the X–axis is:
0 : Not stored.
1 : Stored. See the description of the OX4 bit (bit 1 of parameter 16281).
UOY A tool position compensation value along the Y–axis is:
0 : Not stored.
1 : Stored. See the description of the OY4 bit (bit 2 of parameter 16281).
UTC Under T–axis control, the machine position on the T–axis is:
0 : Not stored.
1 : Stored. The valid data range is 0 to 99999999. (n 4–byte values)
NOTE
When T–axis control is used (TCL bit (bit 4 of parameter
16260) is 1), this bit should be set to 1.
UPC The punching count of an individual tool is:
0 : Not stored.
1 : Stored. See the description of the PC4 bit (bit 4 of parameter 16281).
NOTE
When the tool life management function is used, this bit
should be set to 1.
UCT Tool numbers for changing tools are:
0 : Not stored.
1 : Stored. The number of digits is the same as that for the UT8 bit (bit 0
of parameter 16280).
UTS A graphic tool figure is:
0 : Not stored.
1 : Stored. (n 13–byte values)
UTL The tool life management data is:
0 : Not stored.
1 : Stored. The data is stored in the same way as for the PC4 bit (bit 4 of
parameter 16281).
