Series 16i/18i/160i/180i - PB Connection manual (Function) Page 127

Connection manual (Function)
B–63683EN/01
6. C–AXIS CONTROL
117
[Classification] Output signal
[Function] These signals notify the PMC of whether C–axis independent control or
C–axis synchronization control is applied.
[Output condition] These signals are set to 1 upon power–on in the following cases:
SC1: When C–axis control is applied
SC2: When C–axis synchronization control is applied
(when using the C
1
–axis and C
2
–axis)
These signals are set to 0 in the following cases:
SC1: When C–axis control is not applied
SC2: When C–axis synchronization control is not applied
(when C–axis independent control is applied)
[Classification] Input signal
[Function] C–axis synchronization control is applied when jog feed, handle feed, or
incremental feed is performed.
4
5
6
7
8
The fourth axis is the C
2
–axis.
The fifth axis is the C
2
–axis.
The sixth axis is the C
2
–axis.
The seventh axis is the C
2
–axis.
The eighth axis is the C
2
–axis.
SYNCJn
[Operation] When this signal is set to 1, a move command for the C
1
–axis is also
issued to the C
2
–axis.
Never change the setting of this signal while movement is being
performed.
Set this signal to 0 in other than manual operation mode.
CAUTION
1 During synchronous operation, an input signal provided for
each axis must be entered separately and simultaneously
for the C
1
–axis and C
2
–axis.
2 An output signal provided for each axis is output separately
for the C
1
–axis and C
2
–axis.
Signal
C–axis control status
signal
SC1 <F233#0>
SC2 <F233#1>
Synchronous manual
feed select signal
SYNCJ4 to SYNCJ8
<G140>
