Series 16i/18i/160i/180i - PB Connection manual (Function) Page 172

Connection manual (Function)
9. SAFETY ZONE AREA EXTENSION
B–63683EN/01
162
#7
SZN8F0228
#6
SZN7
#5
SZN6
#4
SZN5
#3
SZN4
#2
SZN3
#1
SZN2
#0
SZN1
#7
SZT16F0238
#6
SZT15
#5
SZT14
#4
SZT13
#3 #2 #1 #0
#7
G0232
#6 #5 #4 #3
SZTS3
#2
SZTS2
#1
SZTS1
#0
SZTS0
Number Message Contents
4804 ZONE : PUNCHING INHIBITED 5 When a safety zone check was executed, a punch command was
specified in area 5 where punching is inhibited.
4805 ZONE : PUNCHING INHIBITED 6 When a safety zone check was executed, a punch command was
specified in area 6 where punching is inhibited.
4806 ZONE : PUNCHING INHIBITED 7 When a safety zone check was executed, a punch command was
specified in area 7 where punching is inhibited.
4807 ZONE : PUNCHING INHIBITED 8 When a safety zone check was executed, a punch command was
specified in area 8 where punching is inhibited.
4818 ZONE : ENTERING INHIBITED 5 +X When a safety zone check was executed, the machine moving in the
positive X direction entered are 5 into which entry is inhibited.
4819 ZONE : ENTERING INHIBITED 5 –X When a safety zone check was executed, the machine moving in the
negative X direction entered are 5 into which entry is inhibited.
4820 ZONE : ENTERING INHIBITED 6 +X When a safety zone check was executed, the machine moving in the
positive X direction entered are 6 into which entry is inhibited.
4821 ZONE : ENTERING INHIBITED 6 –X When a safety zone check was executed, the machine moving in the
negative X direction entered are 6 into which entry is inhibited.
4822 ZONE : ENTERING INHIBITED 7 +X When a safety zone check was executed, the machine moving in the
positive X direction entered are 7 into which entry is inhibited.
4823 ZONE : ENTERING INHIBITED 7 –X When a safety zone check was executed, the machine moving in the
negative X direction entered are 7 into which entry is inhibited.
4824 ZONE : ENTERING INHIBITED 8 +X When a safety zone check was executed, the machine moving in the
positive X direction entered are 8 into which entry is inhibited.
4825 ZONE : ENTERING INHIBITED 8 –X When a safety zone check was executed, the machine moving in the
negative X direction entered are 8 into which entry is inhibited.
4838 ZONE : ENTERING INHIBITED 5 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered are 5 into which entry is inhibited.
4839 ZONE : ENTERING INHIBITED 5 –Y When a safety zone check was executed, the machine moving in the
negative Y direction entered are 5 into which entry is inhibited.
4840 ZONE : ENTERING INHIBITED 6 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered are 6 into which entry is inhibited.
4841 ZONE : ENTERING INHIBITED 6 –Y When a safety zone check was executed, the machine moving in the
negative Y direction entered are 6 into which entry is inhibited.
4842 ZONE : ENTERING INHIBITED 7 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered are 7 into which entry is inhibited.
4843 ZONE : ENTERING INHIBITED 7 –Y When a safety zone check was executed, the machine moving in the
negative Y direction entered are 7 into which entry is inhibited.
Signal address
Alarm and message
