9. SAFETY ZONE AREA EXTENSION
163
Number ContentsMessage
4844 ZONE : ENTERING INHIBITED 8 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered are 8 into which entry is inhibited.
4845 ZONE : ENTERING INHIBITED 8 –Y When a safety zone check was executed, the machine moving in the
negative Y direction entered are 8 into which entry is inhibited.
4854 ZONE : ENTERING INHIBITED 5 Z A command executed in the laser mode brings the Z–axis height into
the approach forbidden area 5. (FS16i–LP: Safety zone check type
B)
4855 ZONE : ENTERING INHIBITED 6 Z A command executed in the laser mode brings the Z–axis height into
the approach forbidden area 6. (FS16i–LP: Safety zone check type
B)
4856 ZONE : ENTERING INHIBITED 7 Z A command executed in the laser mode brings the Z–axis height into
the approach forbidden area 7. (FS16i–LP: Safety zone check type
B)
4857 ZONE : ENTERING INHIBITED 8 Z A command executed in the laser mode brings the Z–axis height into
the approach forbidden area 8. (FS16i–LP: Safety zone check type
B)
