Series 21i/210i - Model B Parameter manual Page 165

Parameter manual

Page of 391

/ 391

B–63610EN/01

4. DESCRIPTION OF PARAMETERS

159

3625 Travel distance per revolution in pitch error compensation of rotation axis type

NOTE

When this parameter has been set, the power must be

turned off before operation is continued.

[Data type] 2–word axis

[Valid data range] 0 to 99999999

If the pitch error compensation of rotation axis type is performed (bit 1

(ROSx) of parameter No. 1006 is set to 0 and bit 0 (ROTx) of parameter

No. 1006 is set to 1), set the travel distance per revolution. The travel

distance per revolution does not have to be 360 degrees, and a cycle of

pitch error compensation of rotation axis type can be set.

However, the travel distance per revolution, compensation interval, and

number of compensation points must satisfy the following condition:

(Travel distance per revolution) = (Compensation interval) x

(Number of compensation points)

The compensation at each compensation point must be set so that the total

compensation per revolution equals 0.

NOTE

If 0 is set, the travel distance per revolution becomes 360

degrees.

3626

Number of pitch error compensation point at the farthest end in the negative

direction (for movement in the negative direction)

NOTE

When this parameter has been set, the power must be

turned off before operation is continued.

[Data type] Word axis

[Unit of data] Number

[Valid data range] 0 to 1023, 3000 to 4023

When using both–direction pitch error compensation, set the number of

pitch error compensation point at the farthest end in the negative direction

for a movement in the negative direction.

NOTE

1 For a movement in the positive direction, set the

compensation point number at the farthest end in the

negative direction in parameter No. 3621.

2 A set of compensation data items for a single axis should not

be set to lie astride 1023 and 3000.
