Series 21i/210i - Model B Parameter manual Page 179

Parameter manual
B–63610EN/01
4. DESCRIPTION OF PARAMETERS
173
3735
Minimum clamp speed of the spindle motor
[Data type] Word
[Valid data range] 0 to 4095
Set the minimum clamp speed of the spindle motor.
Minimum clamp speed of the spindle motor
Set value =
× 4095
Maximum spindle motor speed
NOTE
If the function of constant surface speed control or bit 4
(GTT) of parameter No. 3706 is specified, this parameter is
invalid.
3736
Maximum clamp speed of the spindle motor
[Data type] Word
[Valid data range] 0 to 4095
Set the maximum clamp speed of the spindle motor.
Maximum clamp speed of the spindle motor
Set value =
× 4095
Maximum spindle motor speed
NOTE
If the function of constant surface speed control or bit 4
(GTT) of parameter No. 3706 is specified, this parameter is
invalid.
In this case, the maximum clamp speed of spindle motor
cannot be specified. However, the maximum spindle speed
can be specified by the following parameters.
Parameter No.3772 (for the first axis)
Parameter No.3802 (for the second axis)
