Series 21i/210i - Model B Parameter manual Page 210

Parameter manual

Page of 391

/ 391

4. DESCRIPTION OF PARAMETERS

B–63610EN/01

204

D When bit 6 (ESI) of parameter No.4950=0

Six M code from M a to M(a+5) are used for half–fixed angle

positioning, when a is the value of this parameter.

D When bit 6(ESI) of parameter No.4950=1

Set the start M code in this parameter, and set the number of M codes

in parameter No.4964. Then b M codes from Ma to M(a+b–1) are

used for half fixed angle positioning.

The table below indicates the relationship between the M codes and

positioning angles.

M code Positioning angle

Example: Positioning

angle when q = 30_

Mα θ 30°

M (α+1) 2θ 60°

M (α+2) 3θ 90°

M (α+3) 4θ 120°

M (α+4) 5θ 150°

M (α+5) 6θ 180°

L L L

M (α+n) (n+1) θ

NOTE

q represents the basic angular displacement set in

pamrameter No.4963.

4963

Basic angular displacement used for spindle positioning using M code

[Data type] Word

[Unit of data] deg

[Valid data range] 1 to 60

This parameter sets a basic angular displacement used for half–fixed

angle positioning using M codes.

4964

Number of M codes for specifying a spindle positioning angle

[Data type] Byte

[Unit of data] Integer

[Valid data range] 0, 1 to 255

This parameter sets the number of M codes used for Half–fixed angle

positioning using M codes.

As many M codes as the number specified in this parameter, starting with

the M code specified in parameter No.4962, are used to specify half–fixed

angle positioning.

Let a be the value of parameter No.4962, and let b be the value of

parameter No.4964. That is, M codes from Ma to M (a+b–1) are used for

half–fixed angle positioning.
