Series 21i/210i - Model B Parameter manual Page 343

Parameter manual

Page of 391

/ 391

B–63610EN/01

4. DESCRIPTION OF PARAMETERS

337

8242

#6 #5 #4 #3 #2 #1

BPF

[Data type] Bit

BPF For feed per revolution with the B–axis control function, the parameters

for the unit of PMC feedrate data specification, FR1 and FR2 (bits 6 and 7

of parameter No. 8002) are:

0 : Valid.

1 : Invalid.

8250

Axis number used for B–axis control

[Data type] Byte

[Valid data range] 1 to number of controlled axes

This parameter sets which axis is to be used for B–axis control.

Example of setting:

When the fourth axis is controlled as the B–axis, set 4 in this

parameter. Furthermore, specify a DI/DO number to be used for the

fourth axis in parameter No.8010.

8251

M code (G101) for specifying the start of first program operation

8252

M code (G102) for specifying the start of second program operation

8253

M code (G103) for specifying the start of third program operation

[Data type] 2–word

[Valid data range] 6 to 99999999

These parameters set M codes for starting previously registered B–axis

operation programs. M codes (such as M30, M98, and M99), already

used for other purposes, cannot be set.

8257

T code number for tool offset cancellation

[Data type] Byte

[Valid data range] 0 to 90

This parameter sets a T code number for tool offset cancellation. When

a T code from (setting + 1) to (setting + 9) is specified, tool offset is

specified.
