Series 21i/210i - Model B Parameter manual Page 38

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63610EN/01
32
0813 Logging data length for the FACTOLINK
[Data type] Word
0814 Logging wait address for the FACTOLINK
[Data type] Word
0815 FACTOLINK logging data transmission interval
[Data type] 2-word
0820 FACTOLINK device address (1)
0821 FACTOLINK device address (2)
0822 FACTOLINK device address (3)
0823 FACTOLINK device address (4)
0824 FACTOLINK device address (5)
0825 FACTOLINK device address (6)
0826 FACTOLINK device address (7)
0827 FACTOLINK device address (8)
0828 FACTOLINK device address (9)
[Data type] Byte
See following manuals for the parameters related to the FACTOLINK.
D FANUC Ethernet Board/DATA SERVER Board OPARATOR’S
MANUAL (B-63354EN)
D FANUC FACTOLINK SCRIPT FUNCTION OPERATOR’S
MANUAL (B-75054EN)
