B-63324EN-1/03 OPERATION 8.EDITING PROGRAMS

- 261 -

8.6.2 Replacing Words and Character Strings

Confirming each replacement

Procedure

Method 1

(1) Press the [ALTER] soft key.

(2) Key in the word or character string to be replaced. A list of

multiple words can also be keyed in.

(3) Press the [(WORD)] soft key.

(4) Key in a new word or character string. Multiple words can

also be keyed in.

(5) Press the [EXEC SINGLE] soft key.

The system searches for the character string to be replaced

and the cursor is positioned to the string. If a list of multiple

words is to be replaced, the cursor is positioned to the last

word.

(6) To replace the character string, press the [EXEC SINGLE]

soft key.

The character string is replaced and the system searches for

the next occurrence of the character string.

(7) To search for the next occurrence of the character string

without performing replacement, press the [SKIP] soft key.

The system searches for the next occurrence without

replacing the character string.

(8) To replace all the remaining occurrences of the character

string, press the [EXEC] soft key.

(9) To end the replacement prior to the completion of the search,

press the [STOP] soft key.

(10) Once replacement ends, the total number of replacements is

displayed.

Method 2

(1) Press the [ALTER] soft key.

(2) Key in the word or character string to be replaced, followed

by a new word or character string, as shown in the example.

Multiple words to be replaced and multiple new words can

be entered.

Example: To replace G90 with G91, enter G90,G91.

(3) The subsequent steps are the same as (5) to (10) of method 1.

Method 3

(1) Key in the word or character string to be replaced, followed

by a new word or character string, as shown in the example.

Multiple words to be replaced and multiple new words can

be entered.

Example: To replace G90 with G91, enter G90,G91.

(2) Press the [ALTER] soft key.

The system searches for the character string to be replaced

and the cursor is positioned to the string. If a list of multiple
