Concerning addition of the Changing Active Offset Value with Manual Move Additional Manual Page 1

Additional Manual
FANUC Series 16i /18i
/21i
– TA / TB
Changing Active Offset Value with Manual Move
Index
1. Outline ...........................................................................................................................2
2. Explanation....................................................................................................................2
2.1 Active offset change mode....................................................................................2
2.2 Specifying an offset to be changed.......................................................................2
2.3 Changing the tool compensation .........................................................................3
2.4 Changing the workpiece origin offset.................................................................. 3
2.5 Presetting the relative position indicator ...........................................................4
2.6 Tool life management...........................................................................................4
2.7 Emergency stop and SV alarm ............................................................................4
3. Signal .............................................................................................................................5
4. Parameter ......................................................................................................................7
5. Restriction....................................................................................................................10
6. Caution.........................................................................................................................10
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series16i/18i/21i–TA/TB
Changing Active Offset Value
with Manual Move.
A
-78376
03 Jan.21.’02 Addition and modification of (3)
02 Feb.08.’01 T.Endo Overall revisio H.Kochiya
Jan.16.’01 T.Endo H.Kochiya
1/10
Previous page
Next page

Contents Summary of Concerning addition of the Changing Active Offset Value with Manual Move Additional Manual

  • Page 1FANUC Series 16i /18i /21i – TA / TB Changing Active Offset Value with Manual Move Index 1. Outline ........................................................................................................................... 2 2. Explanation............................................................
  • Page 21. Outline If you want to perform roughing or semi-finishing with a single tool, you may fine-adjust the tool compensation. Moreover, you may want to fine-adjust the setting of the workpiece origin offset that was already set up. This function can change the offset (such as tool compensation or work
  • Page 32.3 Changing the tool compensation This function can change the tool compensation identified by the offset number corresponding to T code specified during automatic operation. If there is no valid tool compensation (for example, when no T code has been issued since cycle start), no tool compensation
  • Page 4Example Assume the following conditions: • Specified workpiece coordinate system: G56 • G56 workpiece origin offset (X-axis): 50.000 • G56 workpiece origin offset (Z-axis): 5.000 • G56 workpiece origin offset (C-axis): 180.000 • G56 workpiece origin offset (Y-axis): -60.000 • Amount of manual feed-b
  • Page 53. Signal Active offset change mode signal CHGAO [Classification] Input signal [Function] This signal selects the manual feed-based active offset change mode. [Operation] Setting this signal to "1" selects the manual feed-based active offset change mode. • Automatic operation is at pause or
  • Page 6Active offset changing signal MCHAO [Classification] Output signal [Function] This signal indicates that the manual feed-based active offset change mode has been selected and the offset is being changed. [Output condition]The signal becomes "1" when all the following conditions are satisfied
  • Page 7The following timing chart shows how the input and signals behave. A command such as Txxxx, or G54 specifies what tool compensation number Operation is put at pause Operation restarts or workpiece coordinate system is to be (stop) to change the offset. with the new offset. made valid. Automatic oper
  • Page 8#7 #6 #5 #4 #3 #2 #1 #0 5000 ASG [ Input type ] Setting input [ Data type ] Bit ASG When the tool geometry/wear compensation function is available, the compensation value changed by this function is: 0: Geometry compensation 1: Wear compensation #7 #6 #5 #4 #3 #2 #1 #0 5040 MOP [ Input type ] Parame
  • Page 9The change of the tool compensation value follows the relation among this parameter, the parameter LVC(No.5003#6), and the parameter TGC(No.5003#7). AOF(No.5041#0)=0 AOF(No.5041#0)=1 LVC(No.5003#6=0) Can be changed LVC(No.5003#6=1) Cannot be changed Cannot be changed TGC(No.5003#7=0) Can be changed
  • Page 10[Relation parameter] #7 #6 #5 #4 #3 #2 #1 #0 5003 TGC LVC [ Input type ] Parameter input [ Data type ] Bit LVC Offset value of tool offset 0: Not cleared, but held by reset 1: Cleared by reset TGC Tool geometry compensation value 0: Not canceled by reset 1: Canceled by reset (Valid when LVC,#6 of pa
