Compound Machining Additional Manual Page 104

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 104/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
Interpolation functions
Item Specifications
Turning
mode
Milling
mode
Positioning Linear interpolation type positioning
is possible.
Ο
Single direction positioning -
I
Exact stop mode - Ο
Exact stop - Ο
Linear interpolation Ο
Circular interpolation Multi-quadrant is possible. Ο
Exponential interpolation -
I
Dwell Dwell in seconds and dwell in revolution Ο
Polar coordinate interpolation
I
Cylindrical interpolation
I
Helical interpolation Circular interpolation plus max. 2 axes
linear interpolation
I
Helical interpolation B Circular interpolation plus max. 4 axes
linear interpolation
-
Involute interpolation -
I
Hypothetical axis interpolation -
Conical/spiral interpolation -
I
Smooth interpolation High-precision contour control is required. -
Threading, synchronous cutting Ο
Multiple threading Ο -
Threading retract
I
-
Continuous threading
I
-
Variable lead threading
I
-
Circular threading
I
-
Polygon turning
I
-
Polygon machining
with two spindles
I
-
Skip Ο
High-speed skip
I
Continuous high-speed skip -
I
