Compound Machining Additional Manual Page 106

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 106/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
Feed functions
Item Specifications
Turning
mode
Milling
mode
Rapid traverse rate Max. 240m/min (1µm) Ο
Max. 100m/min (0.1µm)
S
Rapid traverse override F0, 25, 50, 100% Ο
Feed per minute Ο
Feed per revolution Ο
Feed per revolution
without position coder
Ο -
Tangential speed constant control Ο
Cutting feedrate clamp Ο
Automatic acceleration/deceleration Rapid traverse: linear
Cutting feed: exponential
Ο
Rapid traverse bell-shaped
acceleration/deceleration
I
Positioning by optimal acceleration
I
Linear acceleration/deceleration
after cutting feed interpolation
I
Bell-shaped acceleration/deceleration
after
cutting feed interpolation
I
Linear acceleration/deceleration
before cutting feed interpolation
Feed per minute only
I
Feedrate override 0~254% Ο
2nd feedrate override 0~254%
I
One-digit F code feed -
I
Inverse time feed -
I
Jog override 0~655.34% Ο
Override cancel Ο
Manual per revolution feed Ο -
External deceleration
I
Feed stop
I
Advanced preview control
I
AI contour control -
I
Bell-type acceleration/deceleration
before look ahead interpolation
AI contour control is required.
-
I
High-precision contour control -
NURBS interpolation -
