3.1.2 Tool offset
The parameter setting of TO2(No.xxxx#x) = 1 allows you to
activate/deactivate tool offset not by T code only but G code.
The following format combined with T code and G code is used to start tool
offset.
Tool offset ON
T**: Tool offset number
Tool offset number may be specified by
commanding T code for tool selection.
G43: Tool offset ON
G49 Tool offset CANCEL
• Tool offset behavior is the same as the standard type to command it by T
code only.
• While tool offset is specified, changing offset amount does not become
effective immediately. G43 must be newly commanded.
• G43T00 is equivalent to canceling tool offset.
• Set parameter 5002#5 (LGC) to 1 as geometry offset is cancelled by
specifying tool number to 0.
• The specification of tool nose R compensation is the same as the standard
one’s (G40, G41 and G42).
• Tool offset command is the same as the standard type of M system.
Example)
O0013 ;
N1 M80 ; ← Turning mode start
N2 T0101 ; ← Tool No. 01, Tool offset No. 01
N3 G28 X0 Z0 ;
N4 M06; ← Change to tool No. 01
N5 G43 G00 X100. Z100. ; ← Tool offset No. 01 effective
N6 M3 S1000 ;
N7 G42 Z200. F20 ; ← Tool nose R comp. effective with
N8 X200. ; tool offset No. 01
N9 G03Z100. K-50. ;
N10 G01 G40 X100. ; ← Tool nose R comp. canceled
N11 G49 G00 X0 Z0 ; ← Tool offset canceled
N12 M30 ;
