Compound Machining Additional Manual Page 80

Additional Manual
09 00.11.21 K.Yamamuro Revised to edition 09
08 00.06.22 T.Watanabe Revised to edition 08 T.Endo
01 99.03.10 K.Yamamuro New-registered T.Endo
A-63537E
ED DATE DESIG.
DESCRIPTION 80/134
SHEET
TITLE
FANUC Series 16i/18 i -TA
Compound Machining Function
TITLE
CUST.DRAW.NO.
Turning mode:
In case of parameter 13001#2(DOF)=0, specify a upper two-digit
number in T code
In case of parameter 13001#2(DOF)=1, the entire T code indicates tool
number.
Milling mode:
The entire T code indicates tool number.
Turning mode:
In case of parameter 13001#2(DOF)=0:
Tool offset number is specified by a lower two-digit number in T
code. Upper two-digit (max. six-digit number) indicates tool
number and lower two-digit indicates tool offset number. The
maximum number of the tool offset value specification code which
can be registered is 32, 64, or 99 when tool offset pairs are 32, 64,
or 99 pairs.
In case of parameter 13001#2(DOF)=1:
Tool offset number is specified by D code. Both geometry offset
number and wear offset number are the same.
Milling mode:
Specify H code (for tool length compensation) and D code (for cutter
compensation)
Codes specifying tool offset values are classified into H codes (for
tool length offset) and D codes (for cutter compensation). The
maximum number of the tool compensation value specification
code which can be registered is 255 when there are 400 tool
compensation values. The maximum number is 32, 64, 99, or 200
when there are 32, 64, 99, or 200 tool compensation values.
• Tool number
• Tool offset number
