FA System for PC Operators manual Page 213

Operators manual
B-75044EN/02 APPENDIX B. SAMPLE OPERATION FOR NC
-201-
Procedure for DNC Operation (NC Program Number)
The NC program is selected by “NC Program Number”.
1 Change the NC mode to “MDI”.
2 Push the <SYSTEM> function key.
3 Push the [+] soft key twice.
4 Push the [C-OPER] soft key. The following display will appear.
5 Push the [OPRT] soft key.
6 Push the [STRING] soft key.
7 Input “O????.PRG”. Where, the “????” indicates the NC program
number.
8 Push the [INPUT] soft key.
9 Push the [STRING] soft key.
10 Change the NC mode to “Memory”.
11 Change the NC mode to “RMT” by raising the DNCI signal in the PMC
unit.
12 When the cycle start signal is raised, the DNC operation is started.
[COMMUNICATION OPERATION]
[DNC FILE SELECTION]
-
>
MDI **** **** **** ****
