FA System for PC Operators manual Page 220

Operators manual
B. SAMPLE OPERATION FOR NC APPENDIX B-75044EN/02
-208-
Procedure for Uploading an NC Program (File Name)
The uploaded NC program is saved by using “File Name”.
1 Change the NC mode to “Edit”.
2 To select the PROGRAM(MEMORY) display, push the [PROGRAM]
soft key.
3 Push the [PUNCH] soft key.
4 Push the [PROGRAM#] soft key.
5 Input “????”. Where, the “????” indicates the file name you want to
punch.
6 Push the [EXEC] soft key.
Procedure for Uploading an NC Program (NC Program Number)
The uploaded NC program is saved by using “NC Program Number”.
1 Change the NC mode to “Edit”.
2 To select the PROGRAM(MEMORY) display, push the [PROGRAM]
soft key.
3 Push the [PUNCH] soft key.
4 Push the [FILE#] soft key.
5 Input “??”.
6 Push the [THIS PROGRAM] soft key.
The system can’t name the uploaded NC program by using the file number
which is inputted in the above step 6. but the system finds the NC program
number from the contents of the uploaded NC program and uses it as a file
name.
Procedure for displaying the List
1 Change the NC mode to “Edit”.
2 Push the [PROG] soft key.
3 Push the [DRCTRY FLOPPY] soft key.
4 Push the <PAGE> and <PAGE> key. The pages are turned.
