FA System for PC Operators manual Page 226

Operators manual
C. ERROR CODE APPENDIX B-75044EN/02
-214-
C ERROR CODE
The following error codes are returned by the F_GetLastError function of FA
LIBRARY.
Error Codes about General of Communication Process (0x00010000 ~ 0x0001ffff)
0x00010000 The system cannot terminate the communication process because more than
one machine is communicating with the computer.
Try again after all the machine communications are stopped.
0x00010001 The system cannot open the communication for the specified machine because
it is already communicating with the computer.
The communication of a machine cannot be opened twice.
0x00010002 The system is initializing the DNC1 internal process.
Try again after a short time.
0x00010003 The communication is not opened for the specified machine yet.
Check that the machine was opened correctly.
0x00010006 The communication is not opened for the specified machine yet.
It is possible that the system is not set up correctly.
Error Codes about DNC1 of Communication Process (0x00020000 ~ 0x0002ffff)
0x00020102 The specified machine number is illegal.
Check the machine number is set to the Machine Configuration screen.
0x00020106 During the execution of the function, the system received the request to stop
the DNC1 communication process.
The function is canceled.
0x00020107 The system is replying the other request for the specified machine.
Try again after a short time.
0x0002010c NC program number is illegal.
The range must be from 1 to 9999.
