FA System for PC Operators manual Page 329

Operators manual
10/62
02
04.10.04
Matsukura
SHEETDESCRIPTIONDESIGN DATE EDIT
01 Matsukura First issue
A
dded for version 1.1
TITLE
FANUC FA Library for Windows
OPERATOR’S MANUAL
B-75044EN/02-2
FANUC LTD.
03.09.17
DRAW.NO.
2.1 CNC
This chapter describes about CNCs that can be connected by FA library.
2.1.1 RS-232-C (Reader/Puncher interface) connection
Applicable CNC model
Reader/Puncher can be used on the CNC, except for Series 30i and Series 15i,
supported the Reader/Puncher interface.
FA Library can be connected to a CNC using the Reader/Puncher interface to
be used as a replacement of a FANUC CNC program input/output device as
listed below:
FANUC Handy File
FANUC PROGRAM File / FANUC PROGRAM File Mate
FANUC FLOPPY CASSETTE ADAPTER
FANUC FA CARD ADAPTER
2.1.2 DNC1/Ethernet connection
Applicable CNC model
An Ethernet is required for the following CNCs:
Series 16i -MODEL A/B, Series 160i -MODEL A/B
Series 18i -MODEL A/B, Series 180i -MODEL A/B
Series 21i -MODEL A/B, Series 210i -MODEL A/B
Power Mate i -MODEL D/H
NOTE
1 Cannot connect when the 8-digit program number option is used.
2 Can be used with one-path or two-path control CNC. Cannot be used with
three-path control CNC.
3 The floppy directory display option is required to CNC in order to display
NC program list of FA library.
NOTE
1 Cannot connect when the 8-digit program number option is used.
2 Can be used with one-path or two-path control CNC. Cannot be used with
three-path control CNC.
3 When FA library is operated, one FOCAS1/Ethernet client is used on each
CNC.
