OPERATION11. SETTING AND DISPLAYING DATA

B–64114EN/01

600

This section describes the screens displayed by pressing function key

PROG

in MEMORY or MDI mode.The first four of the following screens

display the execution state for the program currently being executed in

MEMORY or MDI mode and the last screen displays the command values

for MDI operation in the MDI mode:

11.2.1 Program contents display

11.2.2 Current block display screen

11.2.3 Next block display screen

11.2.4 Program check screen

11.2.5 Program screen for MDI operation

Function key

PROG

can also be pressed in MEMORY mode to display the

program restart screen and scheduling screen.

See Section III–4.3 for the program restart screen.

See Section III–4.4 for the scheduling screen.

Displays the program currently being executed in MEMORY or MDI

mode.

Procedure for displaying the program contents

1 Press function key

PROG

to display a program screen.

2 Press chapter selection soft key

[PRGRM].

The cursor is positioned at the block currently being executed.

O2000 ;

N100 G50 X0 Z0. ;

N110 G91 G00 X–70. ;

N120 Z–70. ;

N130 G01 X–60 ;

N140 G41 G03 X–17.5 Z17.5 R17.5 ;

N150 G01 X–25. ;

N160 G02 X27.5 Z27.5 R27.5

N170 G01 X20. ;

N180 G02 X45. Z45. R45. ;

> _ S 0 T0000

MEM STRT *** 16:05:59

[ PRGRM ][ CHECK ][ CURRNT ][ NEXT ][ (OPRT) ]

PROGRAM O2000 N00130

11.2

SCREENS

DISPLAYED BY

FUNCTION KEY @prog

(IN MEMORY MODE OR

MDI MODE)

PROG

11.2.1

Program Contents

Display
