FANUC Series 30i/31i/32i -MODEL A Composite Control Swapping Axis Data Additional Manual Page 1

Additional Manual
A-90123E
Title
Draw
No.
02 Aug.02.’05 Add or Change at 2) part
Ed. Date Design Description
Date Jun.30.’05 Design. Apprv.
1/ 7
page
FANUC Series 30i/31i/32i -MODEL A
Composite control
swa
pp
in
g
axis data
FANUC Series 30i/31i/32i -MODEL A
Composite control
swapping axis data
Specifications

Contents Summary of FANUC Series 30i/31i/32i -MODEL A Composite Control Swapping Axis Data Additional Manual

  • Page 1FANUC Series 30i/31i/32i -MODEL A Composite control swapping axis data Specifications FANUC Series 30i/31i/32i -MODEL A Title Composite control swapping axis data Draw A-90123E No. 02 Aug.02.’05 Add or Change at 2) part Ed. Date Design Description page 1/ 7 Date Jun.30.’05 Design. Apprv.
  • Page 2General In the axis replaced by the composite control, the rapid traverse rate for each axis (parameter 2) No.1420), maximum cutting feedrate for each axis (parameter No.1430). And the axis name can be replaced by G10 command. Another data (aceleration/deceleration and so on) is not changed. Explana
  • Page 3- Maximum cutting feedrate for each axis In the axis replaced by the composite control, the maximum cutting feedrate for each axis can be replaced when the parameter MCFx(No.8169#3) is set to "1". When the composite control is invalid, the original maximum cutting feedrate is used for each axis. Exa
  • Page 4- Axis name 2) During composite control mode, the axis name can be swapped by exchanging the parameters related axis name (No.1020, 1025, 1026) in G10 command. In the composite control mode, the swapped axis name is available in the program, and the axis name is also swapped in the position screen.
  • Page 5- Alarm screen 2) When the axis name is swapped by G10, non-Swapped axis name can be displayed in the alarm screen by setting the parameter MALx(No.8169#4) to 1. Following is the example when axis name is swapped by G10. SV alarm 411 occurs to XB axis in composite control when it moves according to
  • Page 6Caution 2) Caution This function by G10 command swaps over axis name in the position screen. It doesn’t exchange the axis attirbution itself. When both 1st axis (XA) on Path-1 and 1st axis (XB) on Path-2 are in the composite mode and swap over their axis name by G10 command, please give attention to
  • Page 7Parameter 2) #7 #6 #5 #4 #3 #2 #1 #0 8163 MDXx [Input type] Parameter input [Data Type] Bit axis #0 MDXx In composite control, the current position (absolute/relative coordinates) display indicates : 0: Coordinates in the local system. 1: Coordinates in the other system under composite control. #7 #
