Connecting and Maintenance Manual for Fanuc Panel I Additional Manual Page 13

Additional Manual
EDI
T
SHEET
DRAW. NO.
CUS
T
T
ITLE
DESCRIPTION
DESIG.DATE
Connecting and Maintenance Manual
for FANUC PANEL i
A-81000E
13 /
2.2. Environment
When PANEL i is used, the following environmental conditions (as measured top of the PANEL i
inside the cabinet) must be ensured for the PANEL i unit installation.
Ambient temperature Operating : +5～ +45°C
Non-operating : - 20～ +60°C
Change in temperature Up to 20 degrees/hour
Ambient relative humidity Standard : 10 to 75％ (non-condensing)
Short-term(within one month)
: 10 to 90％ (non-condensing)
Maximum Wet Bulb Temperature
: 29°C (Recommended)
Vibration Operating : up to 0.5G
Non-operating : up to 1.0G
Environment Installed in a hermetically sealed cabinet
Altitude Operating : - 60m～ 1000m
Non-operating : - 60m～ 12000m
(*1) Ambient temperature during operation :
The temperature sensor on the PANEL i PCB monitors whether the temperature is within the
specified range.
1) If the temperature at power-on is beyond the allowable range only CNC/PMC is started.
After that if the temperature becomes to within the allowable range, PANEL i automatically
starts.
2) If the temperature drifts out of the allowable range after normal activation, an error occurs
when the hard disk is next accessed.
(*2) Vibration :
The PANEL i unit and built-in hard disk drive may suffer resonance at certain frequencies.
Careful checking is required on the PANEL i unit has been mounted on a machine.
Some development or maintenance options may not satisfy the above specifications.
(*3) Measure for Noise :
Please measure for noise sufficiently referring to CNC’s connection manual.
(*4) Maximum Wet Bulb Temperature :
Recommended specification.
If an operation error or mishap occurs, the data on the hard disk
may be lost, even if all the installation conditions are satisfied.
Therefore, always maintain a backup copy of the data on the hard
disk in case the stored data is lost or damaged.
Especially, the power-off on accessing the hard disk must not be
done because that possibility is very high. Please concern for the
end users
This function is disable when Option for Non-Connecting with
CNC is ordered. PANEL i starts up irrespective of the temperature.
Therefore, the temperature around PANEL i should be watched by the
other method.
04 01.04.01 Sugitani All page changed
