Operator Panels for i Series Controls Operators manual Page 25

Operators manual
1-13
Note
The cables in the Cable Kit are sized for typical installations. Custom
cable lengths may be required for special applications and would be
provided by the machine tool builder.
Figures 1-5, 1-6, and 1-7 on Pages 1-13, 1-14, and 1-15, respectively, illustrate how to apply the +24VDC
Cable Kit with either the LCD-Mount (Integrated) type or the Stand-Alone type i Series hardware. Power
Mate Motion Controllers are only available in a Stand-Alone configuration.
The installation of Stand-Alone type i Series hardware will require a +24VDC cable from the LCD display
to the CNC or PM logic rack. This cable length is determined by the machine tool design and cannot be
included in a standard cable kit. Connectors required for custom cable lengths or for custom installations
must be specified and ordered with the CNC control hardware.
The flexibility of Power Mate i-D & i-H motion controllers as used in their wide variety of applications
makes it difficult to apply a “standardized” power cable kit. A “standard” cable kit may not best fit the
specific requirements of cable types and lengths, required by specific hardware configurations and mounting
distances. The machine tool builder must analyze the power cable requirements based on the application
and installation dimensions. The i-Series Cable Kit 44C742962-G01 may be ordered separately for use in
Power Mate i applications. However, it may not be suitable for the target application. In this case, please
use the connectors supplied with the Operator Panel to create a custom cable set.
Notes :
1. Refer to the appropriate documentation for the +24VDC fusing requirements for your control.
2. Reversing +24VDC polarity to the CNC will damage the Inverter printed circuit board in the CNC.
Check wiring and polarities before applying initial power.
3. North American Operator Panels are rated for 8 Amps maximum on the switched 24VDC circuit.
