Series 16i /18i /21i Additional Manual Page 14
Additional Manual
3)
4)
Note
1. When this parameter is set to “1”, the workpiece coordinate system
preset is executed at the program check mode end regardless of the
parameter WPS (No.3006#6) setting.
2. The absolute coordinate and relative coordinate of the axis, whose
the control axis select signal (PMC axis control) EAX* <G0136> is
“1” at the program check mode start/end or the drawing of the
dynamic graphic display start/end, are not saved/restored.
3. The data of the periodic maintenance screen are not saved/restored.
4. During the program check mode, if G10 command is specified to this
parameter bit, alarm PS5364 occurs.
5. During the program check mode, if the control axis select signal
(PMC axis control) EAX* <G0136> is changed from “0” to “1” or from
“1” to “0”, alarm PS5364 occurs.
5)
#7 #6 #5 #4 #3 #2 #1 #0
3001 PGS
[Data type] Bit
PGS During the program check mode, the M, S, T, and B codes are
0 : Not outputted.
1 : Outputted.
Note
1. When this parameter is set to “1”, the M, S, T, and B codes are not
saved/restored at the program check mode start/end.
Therefore, the M, S, T, and B codes, which are outputted during the
program check mode, are effective after the program check mode end.
2. During the program check mode, if G10 command is specified to this
parameter bit, alarm PS5364 occurs.
Edit
Apprv.
Desig.
Sheet
TITLE
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i/18i/21i–MB, 18i–MB5
Program check function Specifications
A-79461E
02
2004.3.29
Addition of 2)
2004.2.29
14
/
15
03
2004.6.25
Addition of 3)
04
2004.6.30
Addition of 4)
05
2004.7.26
Addition of 5)
