FANUC Series 16i/18i-MB, 18i-MB5
Skip function
for Flexible synchronous control Specifications
A-79507EN
Drawing No.
Title
Page
Example
Mxx ; (flexible synchronous control mode on)
X_ ;
Y_ ;
G31.8 G91 A0 P100 Q30 R1 ;
(skip command for flexible synchronous control)
After 30 times of skip signal inputs, 30 machine coordinate positions of the
A axis are stored respectively in the consecutive custom macro variables
#100~#129.
The total number of skip signal inputs (i.e. 30) is stored in the custom macro
variable #1.
3 Note
1) If α is not the slave axis, the P/S alarm (No.5068) occurs.
2) In the G31.8 block, only one slave axis should be commanded. When
more than one slave axis are specified, the P/S alarm (No.5068) occurs.
3) If G31.8 is commanded out of the flexible synchronous control mode
(Flexible synchronous control mode select signal switching accepted
signal (F197#0 ~ #3) is “0”), the P/S alarm (No.5068) occurs.
4) If P is not specified in the G31.8 block, the P/S alarm (No.5068) occurs.
5) If R is not specified in the G31.8 block, the total number of skip signal
inputs is not stored in the custom macro variables.
6) The number of custom macro variables specified by P and R must be the
existing ones. If any nonexistent variable is specified, the P/S alarm
(No.115) occurs.
If all the variables ranged by P and Q are not among the existing ones,
the P/S alarm (No.115) occurs, too.
7) You can select the type of skip functions, normal skip function or high
speed skip function, by the parameter HSS (No.6200#4).
When high speed skip is selected, you can select a valid signal among
high speed skip signals by setting parameter 9S1 ~ 9S8 (No.6208#0 ~ #7).
8) The servo delay is considered and compensated when storing the
machine coordinate positions to the custom macro variables.
