Update of Servo Software 90B0 for FS15i, FS16i and FS18i (with 320C5410 DSP) Supplement to Manual Page 8
Supplement to Manual
7/11
Descri
p
tion
Design.
DateEd
01.04.20
Taka
y
ama
Newly designed
Notice of the update of Digital
Servo Software 90B0 series
A-62449E-084
FANUC LTD
[Table 1-4] Parameter table for HRV2/HRV3 control (2)
Motor Model
12
3000i
C22
2000i
22
3000i
C30
1500i
30
3000i
40
3000i
M22
4000i
M30
4000i
M40
4000i
M
o
t
or s
p
ec
ifi
ca
ti
on 0243 0246 0247 0251 0253 0257 0265 0268 0272
M
o
t
or
typ
e
N
o. 293 296 297 301 303 307 315 318 322
2001.04.01
Symbol Parameter No.
FS15 FS16
1808 2003
00001000
00001000
00001000
00001000
00001000
00001000
00001000
00001000
00001000
1809 2004
00000011
00000011
00000011
00000011
00000011
00000011
00000011
00000011
00000011
1883 2005
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
1884 2006
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
1954 2010
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
1955 2011
00100000
00000000
00100000
00000000
00000000
00100000
00000000
00000000
00100000
1956 2012
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
00000000
1751 2211
00000000
00001010
00000000
00001010
00001010
00000010
00001010
00001010
00001010
PK1 1852 2040
1701
2320
800
2238
768
640
581
799
712
PK2 1853 2041 -
6391
-
10593
-
4817
-
13330
-
4492
-
4654
-
3844
-
4447
-
4138
PK3 1854 2042 -
1315
-
1347
-
1345
-
1347
-
1347
-
1348
-
1337
-
1317
-
1341
PK1V 1855 2043
192
271
198
166
230
191
69
82
92
PK2V 1856 2044 -
1721
-
2426
-
1775
-
1486
-
2057
-
1712
-
616
-
733
-
827
PK3V 1857 2045
0
0
0
0
0
0
0
0
0
PK4V 1858 2046 -
8235
-
8235
-
8235
-
8235
-
8235
-
8235
-
8235
-
8235
-
8235
POA1 1859 2047
2204
1565
2137
2553
1845
2216
6163
5175
4589
BLCMP 1860 2048
0
0
0
0
0
0
0
0
0
DPFMX 1861 2049
0
0
0
0
0
0
0
0
0
POK1 1862 2050
956
956
956
956
956
956
956
956
956
POK2 1863 2051
510
510
510
510
510
510
510
510
510
RESERV 1864 2052
0
0
0
0
0
0
0
0
0
PPMAX 1865 2053
21
21
21
21
21
21
21
21
21
PDDP 1866 2054
1894
1894
1894
1894
1894
1894
1894
1894
1894
PHYST 1867 2055
319
319
319
319
319
319
319
319
319
EMFCMP 1868 2056
0
0
0
0
-
20500
0
0
0
0
PVPA 1869 2057 -
8199
-
2597
-
5136
-
1545
-
5170
-
2570
-
7687
-
6412
-
5645
PALPH 1870 2058 -
747
-
1942
-
2800
-
1300
-
1000
-
2000
-
2000
-
2300
-
3000
PPBAS 1871 2059
0
0
0
0
0
0
0
0
0
TQLIM 1872 2060
7282
8010
7282
7282
7282
7282
7282
7282
7282
EMFLMT 1873 2061
0
0
0
0
0
0
0
0
0
POVC1 1877 2062
32520
32114
32520
32520
32511
32511
32555
32511
32511
POVC2 1878 2063
3101
8171
3101
3101
3215
3215
2663
3215
3215
TGALMLV 1892 2064
4
4
4
4
4
4
4
4
4
POVCLMT 1893 2065
9224
24454
9224
9224
9565
9565
7917
9565
9565
PK2VAUX 1894 2066
0
0
0
0
0
0
0
0
0
FILTER 1895 2067
0
0
0
0
0
0
0
0
0
FALPH 1961 2068
0
0
0
0
0
0
0
0
0
VFFLT 1962 2069
0
0
0
0
0
0
0
0
0
ERBLM 1963 2070
0
0
0
0
0
0
0
0
0
PBLCT 1964 2071
0
0
0
0
0
0
0
0
0
SFCCML 1965 2072
0
0
0
0
0
0
0
0
0
PSPTL 1966 2073
0
0
0
0
0
0
0
0
0
AALPH 1967 2074
8192
4096
8192
8192
4096
4096
4096
4096
4096
MODEL 1968 2075
0
0
0
0
0
0
0
0
0
WKAC 1969 2076
0
0
0
0
0
0
0
0
0
OSCTPL 1970 2077
0
0
0
0
0
0
0
0
0
PDPCH 1971 2078
0
0
0
0
0
0
0
0
0
PDPCL 1972 2079
0
0
0
0
0
0
0
0
0
DPFEX 1973 2080
0
0
0
0
0
0
0
0
0
DPFZW 1974 2081
0
0
0
0
0
0
0
0
0
BLENDL 1975 2082
0
0
0
0
0
0
0
0
0
MOFCTL 1976 2083
0
0
0
0
0
0
0
0
0
SDMR1 1977 2084
0
0
0
0
0
0
0
0
0
SDMR2 1978 2085
0
0
0
0
0
0
0
0
0
RTCURR 1979 2086
2085
2911
2131
1655
2306
1957
1449
1836
2073
TDPLD 1980 2087
0
0
0
0
0
0
0
0
0
MCNFB 1981 2088
0
0
0
0
0
0
0
0
0
BLBSL 1982 2089
0
0
0
0
0
0
0
0
0
ROBSTL 1983 2090
0
0
0
0
0
0
0
0
0
ACCSPL 1984 2091
0
0
0
0
0
0
0
0
0
ADFF1 1985 2092
0
0
0
0
0
0
0
0
0
VMPK3V 1986 2093
0
0
0
0
0
0
0
0
0
BLCMP2 1987 2094
0
0
0
0
0
0
0
0
0
AHDRTL 1988 2095
0
0
0
0
0
0
0
0
0
RADUSL 1989 2096
0
0
0
0
0
0
0
0
0
SMCNT 1990 2097
0
0
0
0
0
0
0
0
0
DEPVPL 1991 2098
0
0
0
0
0
0
0
0
0
ONEPSL 1992 2099
400
400
400
400
400
400
400
400
400
INPA1 1993 2100
0
0
0
0
0
0
0
0
0
INPA2 1994 2101
0
0
0
0
0
0
0
0
0
DBLIM 1995 2102
15000
0
15000
0
0
15000
0
0
0
ABVOF 1996 2103
0
0
0
0
0
0
0
0
0
ABTSH 1997 2104
0
0
0
0
0
0
0
0
0
TRQCST 1998 2105
517
680
929
1630
1170
1839
1216
1470
1701
LP24PA 1999 2106
0
0
0
0
0
0
0
0
0
VLGOVR 1700 2107
0
0
0
0
0
0
0
0
0
RESERV 1701 2108
0
0
0
0
0
0
0
0
0
BELLTC 1702 2109
0
0
0
0
0
0
0
0
0
MGSTCM 1703 2110
32
1548
1291
2059
1032
1291
519
775
776
DETQLM 1704 2111
0
2600
0
2148
7735
5140
6224
6450
5682
AMRDML 1705 2112
0
0
0
0
0
0
0
0
0
NFILT 1706 2113
0
0
0
0
0
0
0
0
0
NINTCT 1735 2127
2388
3695
3272
6680
1688
3041
2041
1871
1853
MFWKCE 1736 2128
2000
4000
4500
14000
2500
2000
2500
4000
4000
MFWKBL 1752 2129
2568
1046
1301
539
2829
1553
2580
2574
2063
LP2GP 1753 2130
0
0
0
0
0
0
0
0
0
LP4GP 1754 2131
0
0
0
0
0
0
0
0
0
LP6GP 1755 2132
0
0
0
0
0
0
0
0
0
PHDLY1 1756 2133
0
2070
0
1054
5140
3087
5150
5150
5150
PHDLY2 1757 2134
0
5160
0
5160
5155
5150
5150
5150
5148
DGCSMM 1782 2159
0
0
0
0
0
0
0
0
0
TRQCUP 1783 2160
0
0
0
0
0
0
0
0
0
RESERV 1784 2161
0
0
0
0
140
140
140
140
140
POVC21 1785 2162
32765
32761
32765
32766
32764
32765
32767
32766
32765
POVC22 1786 2163
38
83
40
23
48
33
18
29
38
POVCLMT2
1787 2164
6924
13493
7229
4361
8466
6099
3345
5369
6846
MAXCRT 1788 2165
85
45
85
85
165
165
165
165
165
