Spindle Learning Control Manual Additional Manual Page 5

Additional Manual
5/22
Design.
DateEd.
2002.05.06
SHEET
DRAW. No.
CUST.
TITLE
M.Niwa
Newly preparation
Spindle Learning Control Description
A-53866E-0425
FANUC LTD
01
2.1.4. Example 3 : In case of semi-closed system with gear reduction
JA7A
JYA2
SPM
TYPE B
JA7B
JX4
JYA2
SPM
TYPE B
JA7B
JX4
JYA3
JYA3
external
one-rotation
signal
(proximity
switch
)
Spindle
motor
Spindle
shaft
1st spindle
(master axis)
2nd spindle
(slave axis)
velocity and
position sensor
external
one-rotation
signal
(proximity
switch
)
Spindle
motor
Spindle
shaft
velocity and
position sensor
communication
between SPMs
CNC
Series
16i/160i/160is
18i/180i/180is
MODEL B
parameter settings related to sensors
parameter settings description
4000#0 depends on the
configuration
rotation directions of the spindle and motor
4002#3,2,1,0 0,0,0,1 uses the motor sensor for position feedback.
4003#7,6,5,4 0,0,0,0 It is not necessary to set number of sensors in this case
4004#2 1 uses the external one-rotation signal (proximity switch)
4004#3 depends on
sensor type.
sets the external one-rotation signal (proximity switch) type
4010#2,1,0 0,0,1 MZi / BZi sensor
1,0,1 3rd party sensor (MZi / BZi sensor compatible reference signal)
1,1,1 3rd party sensor (driver type reference signal)
4011#2,1,0
or 4334
depends on
sensor type.
sets the number of motor sensor gear teeth.
4056~4059 depends on the
configuration
sets gear ratio between the spindle shaft and motor shaft
4171~4174 depends on the
configuration
sets gear ratio between the spindle shaft and motor shaft
4386* depends on
sensor type.
sets the number of motor sensor (velocity sensor) gear teeth of
master axis
4498, 4499* depends on the
configuration
sets gear ratio between the spindle shaft of master and motor shaft of
master axis.
* These parameters are valid only for slave axis (2nd spindle)
Previous page
Next page
