  2. FANUC Series30i/31i/32i-MODEL A, Simultaneous Displaying Axis Number Expansion Function

FANUC Series30i/31i/32i-MODEL A, Simultaneous Displaying Axis Number Expansion Function Additional Manual Page 2

Additional Manual
FD
App
r
y
Desi
g
n
Page
Title
2
/
1
3
Data
Desi
g
n Description
Data
FANUC Series30i /31i /32i -MODEL A
Simultaneous displaying axis number expansion
function
AD-02002613E
05.04.08
Tanaka
Draw
No.
1.1 SIMULTANEOUS DISPLAYING AXIS NUMBER EXPANSION FUNCTION
General
The number of axis data “current position “ and “Distance to go” that are displayed
on the same screen can be expanded up to 20.
Details
In initial setting, the maximum number of simultaneous displaying axis of carrent
position is for 5. In this function, the max number of simultaneous displaying axes
can be selected from 5, 10 and 20 axes by setting the parameter No.11305.
The relation of the max number of simultaneous displaying axes and a set value of
parameter is shown in the following table.
Table. 1.1 (a) The related of the max number of simultaneous
displaying axes and a set value of parameter
the max number of
simultaneous
displaying axes
Parameter
（No.11305）
5 0
10 1
20 2
When the number of axes is more than that of the max number of simultaneous
displaying axis, you can change to the axis coordinates of the remainder by pushing
the chapter selection key.
（Example）When 13 axes（X1∼X13）are displayed by each max number of
simultaneous displaying axes, the display of coordinates is shown in following
figures.
