FANUC PANEL i Additional Manual Page 17

Additional Manual
Connecting Manual
For FANUC PANEL i
EDIT
DRAW. NO. CUST
TITLE
DESCRIPTION
DESIG.
DATE
A
-83125E
17
/
SHEET
1) RECOMMENDED CABLE MATERIAL
For RS232-C : A66L-0001-0284#10P・・・0.08mm2 10 pairs
For USB : Please use special wire for USB
2) RECOMMENDED PUNCH PANEL
For RS232-C : A02B-0236-C191 (1m), A02B-0236-C192 (2m), A02B-0236-C193 (5m)
For RS232-C, USB, Parallel port : A08B-0082-C200
RS232-C, USB Cable for A08B-0082-C200 : A08B-0082-K810
Parallel port Cable for A08B-0082-C200 : A08B-0082-K811
Parallel port Keyboard and mouse for A08B-0082-C200 : A08B-0082-K812
3) RECOMMENDED CONNECTOR FOR CABLE and HOUSING(JD46 side）
CONNECTOR HOUSING MAKER
PCR-E20FA PCR-V20LA/PCS-E20LA (Honda Tsushin Kogyo)
FI30-20S FI-20-CV2/FI-20-CV7 (Hirose Electric)
FCN-247J020-G/E FCN-240C020-Y/S (Fujitsu)
52622-2011 52624-2015 (Molex Japan)
The other punch panel (A02B-0120-C191 – C193) for CNC cannot be
used on the PANEL i. If inappropriate punch panel is used, a
system can’t run or serious failure may happen.
(3)
(3)
03
Information about USB is added
