  2. FANUC Series 30i/ 31i/ 32i Live Tool Control With Servo Motor Specifications

FANUC Series 30i/ 31i/ 32i Live Tool Control With Servo Motor Specifications Additional Manual Page 28

Additional Manual
A-79805E
Title
Draw
No.
28/40
Sheet
FANUC Series 30i/ 31i/ 32i
Live Tool Control With Servo Motor
Edit
Apprv.Desig.
Date
Design
Descri
p
tion
Date
Oct.26.2004
#7 #6 #5 #4 #3 #2 #1 #0
11000 SRV
NOTE
When this parameter is set, the power must be turned
off before operation is continued.
[Input type] Parameter input
[Data type] Bit axis
# 7 SRV Live tool control with servo motor is
0: No used.
1: Used.
11010 Spindle number used by live tool control function
NOTE
When this parameter is set, the power must be turned
off before operation is continued.
[Input type] Parameter input
[Data type] Byte axis
[Valid data range] 0 to Number of controlled spindles
11011 Movement of live tool axis per revolution
NOTE
When this parameter is set, the power must be turned
off before operation is continued.
[Input type] Parameter input
[Data type] Real axis
[Valid data range] 0 to 999999.999
11013 Positioning deviation limit for each axis in movement
11014 Positioning deviation limit for each axis in the stopped state
[Input type] Parameter input
[Data type] 2-word axis
[Unit of data] Detection unit
[Valid data range] 0 to 99999999
These parameters are effective at the SVspeed control mode.
