FANUC Series 30i/31i/32i -MODEL A
Tool management function
magazine property/pot property
1.2 Parameter
#7 #6 #5 #4 #3 #2 #1 #0
13240 MT8 MT7 MT6 MT5
NOTE
When this parameter is set, the power must be turned
off before operation is continued.
[Input type] Parameter input
[Data type] Bit type
# 4 MT5 The fifth magazine is
0: Chain type
1: Matrix type
When this parameter is set to 1, the parameter No.13270 is invalid.
# 5 MT6 The sixth magazine is
0: Chain type
1: Matrix type
When this parameter is set to 1, the parameter No.13272 is invalid.
# 6 MT7 The seventh magazine is
0: Chain type
1: Matrix type
When this parameter is set to 1, the parameter No.13274 is invalid.
# 7 MT8 The eighth magazine is
0: Chain type
1: Matrix type
When this parameter is set to 1, the parameter No.13274 is invalid.
